Imaging
Lens Mount Micro Four Thirds
Sensor Resolution Actual: 17.2 Megapixel
Effective: 16.1 Megapixel (4608 x 3456)
Sensor Type 17.4 x 13 mm (4/3") MOS
Crop Factor 2x
Image Stabilization Sensor-Shift, 5-Axis
Exposure Control
Shutter Speed Mechanical Shutter
1/4000 to 60 Seconds
0.5 60 Minutes in Bulb Mode
Electronic Front Curtain Shutter
1/320 to 60 Seconds
Electronic Shutter
1/16000 to 30 Seconds
Metering Method Center-Weighted Average, Multi-Zone, Spot
Exposure Modes Aperture Priority, Auto, Manual, Program, Shutter Priority
Exposure Compensation -5 to +5 EV (1/3 EV Steps)
Metering Range -2 to 20 EV
Continuous Shooting Up to 8.6 fps at 16.1 MP for up to 22 Frames (Raw) / 36 Frames (JPEG)
Up to 4.8 fps at 16.1 MP for Unlimited Frames
Interval Recording Yes
Self-Timer 2/12-Second Delay
Aspect Ratio 4:3
Image File Format JPEG, Raw
Bit Depth 12-Bit
Broadcast Output NTSC/PAL
Interface
Media/Memory Card Slot Single Slot: SD/SDHC/SDXC (UHS-II)
Internal Memory None
Monitor
Size 3.0"
Resolution 1,040,000 Dot
Display Type Tilting Touchscreen LCD
Viewfinder
Type Built-In Electronic
Resolution 2,360,000 Dot
Eye Point 19.2 mm
Coverage 100%
Magnification Approx. 1.23x
Diopter Adjustment -4 to +2
Focus
Focus Type Auto and Manual Focus
Focus Mode Continuous-Servo AF, Manual Focus, Single-Servo AF
Autofocus Points Contrast Detection: 121
Flash
Built-In Flash Yes
Flash Modes Auto, Fill Flash, Manual, Red-Eye Reduction, Slow Sync, Slow Sync/Red-Eye Reduction
Guide Number 19.03' / 5.8 m at ISO 100
Maximum Sync Speed 1/250 Second
Flash Compensation -3 to +3 EV (1/3 EV Steps)
Dedicated Flash System TTL
External Flash Connection Hot Shoe
Environmental
Operating Temperature 14 to 104°F / -10 to 40°C
Operating Humidity 30 to 90%
Battery Type 1 x BLS-50 Rechargeable Lithium-Ion, 7.2 VDC, 1175 mAh
